P-sensor

Product Features
● ALS and PS, built-in LED in a single chip;
● Convert light intensity into digital data format;
● Digital control and data output through I2C (100 KHz and 400 KHz) interface;
● Programmable analog gain and integration time of ALS and PS;
● Integrated LED driver for short-range detection;
● Environmental infrared elimination during close sensing;
● Programmable interrupt function of ALS and PS with upper and lower limits;
● Working voltage range: 1.65V to 2.0V;
● ALS mode working current: 225uA;
● Sleep mode: 1uA typical current.
Applications
● Smartphone
● Buying laptop
● Tablet PC, TV
● Consumer electronics and appliances

Sample Request

Supply voltage（V)	Supply current（uA)	Feature	ADC：Resolution	Maximum detection range	Emission wavelength
1.65-2	Working current 125uA；Non-working current 1uA	Ambient light sensor	12-16 bit	100k lux	/
1.65-2	Working current 225uA；Non-working current 1uA	Integrated proximity and ambient light sensor with built-in LED	12-16 bit	100k lux	940nm
